Allen & Heath ZED-6FX Compact 6 Input Analogue Mixer with FX
The Allen & Heath ZED-6FX is a compact analogue mixer designed for small setups, live performance, and home recording. It offers essential inputs, built-in effects, and reliable audio performance in a portable format.
Flexible Input Configuration
The mixer includes 2 mic/line inputs with XLR and TRS connections, along with 2 stereo inputs. This allows you to connect microphones, instruments, and playback devices in one setup. It supports small live sessions, streaming, and recording.
GS-Pre Microphone Preamps
Equipped with GS-Pre preamps, the mixer delivers low noise and consistent gain. This helps capture clear vocals and instruments while maintaining control over different input levels.
Hi-Z Instrument Inputs
Two Hi-Z inputs allow direct connection of guitars and other high-impedance instruments. This removes the need for a separate DI box and simplifies setup for musicians.
Built-In FX Engine
The internal FX engine includes 61 presets such as reverb, delay, and modulation. Tap tempo control helps keep effects in sync, making it useful for live performance and recording.
EQ and Low Cut Control
Each mono channel features a 2-band EQ and a low-cut filter. These controls help adjust tone and remove unwanted low frequencies, improving overall sound clarity.
Reliable Output and Control
XLR main outputs provide a stable connection to speakers or recording gear. The 60mm master fader allows precise control over the main output level.
Phantom Power Support
48V phantom power enables the use of condenser microphones, expanding compatibility for studio and live applications.
- 1x Stereo Master Output
- 1x Stereo Headphone Output
- Low: at 80 Hz
- High: at 12 kHz
- 2x XLR 3-Pin Mic Input
- 2x 1/4 in TRS Line Input
- 4x 1/4 in TRS Line Input (2 Stereo Pairs)
- 2x XLR 3-Pin Main Output
- 1x 1/4 in TRS Headphone Output
- 1x 1/4 in FX Output
Mixer
| Number of Analog Input Channels | 6 (2 Mono / 2 Stereo) |
| Number of Mic Preamps | 2 |
| Analog Output Channels | |
| Mix Routing | Main Mix / Bus/Subgroup |
| Faders & Level Adjustment | 4x Channel Fader |
| Meters | Main Meter: 2x 8-Segment LED |
Signal Processing
| EQ | 2-Band EQ |
| EQ Parameters | |
| Graphic EQ | No |
| Filters | 2x High-Pass: 100 Hz |
| Solo/Mute | No |
| Built-In Effects | Yes |
Connectivity
| Analog Inputs | |
| Analog Outputs | |
| Phantom Power | Yes |
| Digital I/O | No |
| Wireless | No |
Power
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
Physical
| Rack Mountable | No |
| Dimensions | 3.5 x 9.8 x 9.3 in / 88.9 x 246.4 x 236.2 mm |
| Weight | 3 lb / 1.4 kg |
Packaging Info
| Package Weight | 4.95 lb |
| Box Dimensions (LxWxH) | 14.9 x 12 x 5.6 in |
