The Next Generation in Loudspeaker Management
All the processing power you need to supercharge your sound system—now with full mobile control.
Building on the industry-dominating DriveRack 260, the dbx DriveRack VENU360 is the evolution professionals have been waiting for. With 3 inputs and 6 outputs, expanded connectivity, and intelligent processing features, the VENU360 puts total control of your system in your hands—literally. Seamlessly manage your sound from any Android, iOS, Mac, or Windows device via Ethernet, with a sleek interface designed for fast, flexible operation.
Key Features:
Optimized Sound with AutoEQ
The newly refined AutoEQ algorithm delivers fast, precise, and hassle-free automatic room tuning using real-time analysis and sine sweeps, not disruptive pink noise. Now located in the output stage, AutoEQ allows individual system zones (like FOH, monitors, and delays) to be equalized independently for maximum control.
Worry-Free Performance with Enhanced AFS
The enhanced Advanced Feedback Suppression (AFS) listens ahead and neutralizes feedback before it ruins your show, without compromising your tone. It's smarter, faster, and more transparent than ever.
Smarter Setup with Updated Wizards
Get up and running in minutes with redesigned Wizard setup functions. Configure routing, level balancing, AutoEQ, AFS, and speaker tunings with step-by-step guidance. With access to the latest tunings from leading speaker brands, plus a dedicated Monitor Wizard, you’re always ready for any setup.
Complete Mobile Control
Take full command of your mobile device. Whether you’re on stage or across the venue, adjust EQs, compressors, crossovers, and speaker profiles using the powerful app with an intuitive graphical interface.
Input Processing
- dbx Compression
- AFS (Advanced Feedback Suppression)
- 31-Band Graphic EQ
- 12-Band Parametric EQ (with narrow notch capabilities)
- Subharmonic Synthesis
- Backline Delay
- Noise Gate
Output Processing
- Crossover (supports full range up to mono 6-way systems)
- 12-Band AutoEQs (8 AutoEQ bands, 4 User bands)
- dbx Compression
- Automatic Gain Control
- Subharmonic Synthesis
- Noise Gate
- Tower Delays (up to 1000ms per output)
- 8-Band Parametric EQs (used for speaker tunings)
- dbx Limiting
- Driver Alignment Delays
Main
| Configuration | Core |
| Color | Black/Black |
DBX DBXVENU360-V 3X6 Loudspeaker Management System with AutoEQ, Enhanced AFS Feedback Elimination
| Input | (3) analog line inputs/(2) AES digital inputs (shared connectors), (1) RTA mic input |
| Input Connectors | (3) female XLRs (2 selectable between analog/AES digital audio formats), (1) female XLR RTA mic input |
| Input Type | Electronically balanced/RF filtered |
| Input Impedance | > 30 kΩ, balanced line to line |
| Max Input Level (line inputs) | > +28 dBu, balanced, ≤1% THD |
| CMRR | > 50 dB @ 1 kHz |
| RTA Mic Preamp Phantom Power | +48 VDC |
| Output | (6) Line Outputs |
| Output Connectors | Male XLR |
| Output Type | Electronically balanced, RF filtered |
| Output Impedance | 120 Ω, balanced line to line |
| Max Output Level | +22 dBu, balanced, ≤1% THD |
| Alignment Delay | Up to 1000 ms per output channel |
| A/D Converter | 24-bit with dbx Type IV™ Conversion System |
| A/D Dynamic Range | 117 dB A-weighted, 114 dB unweighted, 22 kHz BW |
| D/A Converter | 24-bit |
| D/A Dynamic Range | 116 dB A-weighted, 113 dB unweighted, 22 kHz BW |
| Internal Processing Wordlength | 32-bit floating point |
| Supported Sample Rates | 48/96 kHz (32-192 kHz using sample rate conversion) |
| System Performance Dynamic Range | 114 dB A-weighted; 110 dB unweighted |
| THD+Noise | 0.0025% typical at +4 dBu, 1 kHz, 0 dB input gain |
| Frequency Response | 20 Hz – 20 kHz, +0 /- 0.5 dB |
