Electro Voice ELX200 10P 10 Inch 1200W 2 Way Powered Black Loudspeaker
The Electro-Voice ELX200-10P Powered Loudspeaker in Black features high-efficiency Class-D power amplifiers (up to 1200 W) with integrated QuickSmartDSP and delivers up to 130 dB SPL utilizing transducers designed and engineered by EV (10-inch EVS-10M woofer coupled with a DH-1L 1-inch titanium compression driver). It allows easy setup via four presets (Music, Live, Speech, Club), sub and top system-match crossovers, three-band EQ, five user-programmable presets (store and recall settings), visual monitoring of limiter status, input level control and meters, and master volume control to ensure optimal gain structure. EV-patented Signal Synchronized Transducers (SST) waveguide design provides precise and consistent coverage, minimal distortion, and maximized acoustical loading.
Portable and Lightweight
It is ideal for portable and installed applications, with lightweight and durable polypropylene enclosures, three M10 threaded mounting points, and the proven ZLX handle design for easy lifting.
QuickSmart Mobile Wireless Control
The new QuickSmart Mobile wireless control and monitoring application, using Bluetooth Low Energy (BTLE) technology, allows intuitive system control, configuration, and monitoring of up to six powered ELX200 loudspeakers simultaneously. Receive alerts when your system is being overdriven, and control your system while in front of your speakers, not behind.
System
| Watts | 1200 |
| Bluetooth Type | Bluetooth |
| Speaker Configuration | 2-Way |
| Amplifiers | 1 x Class-D |
Power
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
| Power Source | AC Power Adapter |
Physical
| Material | Polypropylene |
| Weight | 29.9 lbs. |
| Color | Black |
Connectivity
| Audio Output | 1 x XLR 3-Pin |
| Audio Input | 2 x Combo XLR-1/4" TRS |
Electro-Voice ELX200-10P 10-Inch 2-Way Powered Loudspeaker with Integrated QuickSmartDSP (Black)
| Color | Black |
| Frequency Response (Minus 3 dB) | 59 Hz -18 kHz |
| Frequency Range (Minus 10 dB) | 53 Hz - 20 kHz |
| Maximum SPL | 130 dB2 |
| Coverage (H x V) | 90 x 60-degree |
| Power Rating | 1200 W |
| LF Transducer | EVS-10M 10-inch (254 mm) |
| HF Transducer | DH-1L 1-inch titanium compression driver |
| Crossover Frequency | 1800 Hz |
| Connectors | One stereo RCA input, 2 XLR/TRS combo jack, and one XLR |
| Enclosure | Polypropylene |
| Grille | 18 AWG steel with powder coat |
| Suspension | 3 M10 suspension points |
| Dimensions (H x W x D) | 21 x 13 x 12.6-inch (531 x 330 x 319 mm) |
| Net Weight | 29.9 lb (13.5 kg) |
| Power Consumption | 100 - 240 V, 50 - 60 Hz, 1.2 - 0.6A |
