Korg Nu:Tekt NTS-4 Compact 6-Channel Performance Mixer with Modular Connectivity and Effects
Product highlights
Product highlights
In the box
In the box
Free standard shipping
Free standard shipping
*Orders placed before 1 PM EST Mon - Thur will ship the same day. Orders placed beyond these hours will be shipped the next business day. Exclusions apply. See shipping policy
Free Local Pickup
Free Local Pickup
Please call for store stock availability. Requests made before 2:30 PM EST can be available for next-day pickup. Learn more
The Korg Nu:Tekt NTS-4 is a compact six channel performance mixer kit built for hardware musicians who need a centralized way to combine synths, drum machines, modular equipment, and other desktop instruments. Four stereo inputs and two mono inputs support up to 10 audio signals, while dedicated stereo SEND and RETURN connections make it easy to bring external effects into the signal path. Standard 6.3 mm main outputs provide a practical connection to downstream audio equipment.
Hands On Mixing and Effects
Two independent stereo effects engines provide sound shaping directly from the mixer. Each channel has a SEND FX control for effects including delay, reverb, and chorus, while the master TOTAL FX engine provides filters, modulation, drive, distortion, compression, and limiting. Dedicated CUE and MUTE buttons support real time performance control, and the CUE system lets you monitor an individual channel through headphones before adding it to the main mix.
Hardware and Computer Connectivity
The mono inputs can be configured for either line level or modular level before assembly, making the NTS-4 adaptable to compact synthesizers and Eurorack systems. USB Type-C connectivity supports 48 kHz / 24 bit digital audio with compatible computers and mobile devices. USB MIDI can receive messages from a DAW and route them through the dedicated MIDI OUT connection to external hardware.
Durable and Reliable Mixer
A steel chassis gives the mixer a stable desktop footprint while keeping the overall size to 195 x 125 x 38 mm and the weight to 613 g. The NTS-4 is supplied as a user assembled Nu:Tekt kit and includes a USB Type-C to Type-A cable along with assembly instructions.
Mixer
| Channels | 6 |
| Stereo Input Channels | 4 |
| Mono Input Channels | 2 |
| Maximum Supported Audio Signals | 10 |
Input Jacks
| MONO 1-2 | 2 x 3.5 mm Monaural Mini Phone Jack, Unbalanced |
| STEREO 1-4 | 4 x 3.5 mm Stereo Mini Phone Jack, Unbalanced |
| RETURN | 3.5 mm Stereo Mini Phone Jack, Unbalanced |
Output Jacks
| MAIN OUT L | 6.3 mm Monaural Phone Jack, Unbalanced |
| MAIN OUT R | 6.3 mm Monaural Phone Jack, Unbalanced |
| Headphone | 3.5 mm Stereo Mini Phone Jack, Unbalanced |
| SEND | 3.5 mm Stereo Mini Phone Jack, Unbalanced |
Other Connections
| MIDI OUT | 3.5 mm TRS Mini Phone Jack |
| USB Port | USB Type-C |
Built-in effects
| SEND FX | Delay, Ping Pong Delay, Hall Reverb A, Hall Reverb B, Slap Reverb A, Slap Reverb B, Chorus |
| TOTAL FX | LPF, HPF, Isolator, Flanger, Phaser, Decimator, Drive, Distortion, Compressor, Limiter |
Digital Audio
| USB Audio Resolution | 48 kHz / 24 bit |
| USB MIDI | Supported |
Display
| Display Type | 7-segment LED display (3 digits) |
Power
| Power Supply | USB Bus Power |
| Alternative Power Supply | DC 9 V AC Adapter |
| AC Adapter | Sold Separately |
| No Load Power Consumption | 0.1 W at 230 V |
Construction
| Chassis Material | Steel |
| Assembly | User Assembled Kit |
Dimensions and Weight
| Dimensions | 195 x 125 x 38 mm |
| Weight | 613 g |
