Yamaha MGP32XA 32 Channel Analog Mixing Console with USB Device Recording
Product highlights
Product highlights
In the box
In the box
Free standard shipping
Free standard shipping
*Orders placed before 3 PM EST Mon - Friday will ship the same day. Orders placed beyond these hours will be shipped the next business day. Exclusions apply. See shipping policy
Free Local Pickup
Free Local Pickup
Please call for store stock availability. Requests made before 2:30 PM EST can be available for next-day pickup. Learn more
The Yamaha MGP32XA brings 32 line inputs, 24 mic inputs, flexible bus routing, onboard processing, and USB device recording into one hands-on analog mixing surface. It gives sound engineers direct access to channel controls for live events, installed systems, rehearsals, and production spaces while adding digital tools that reduce the need for separate processors.
Analog Control with Yamaha Processing
Discrete Class A D-PRE microphone preamps support the mono input channels, with 48V phantom power available per channel and a 100 Hz high-pass filter. X-pressive EQ adds focused tone shaping, while 1 Knob compressors on channels 9 through 24 simplify dynamic control. The stereo master adds graphic EQ plus standard and multiband compression, giving the operator additional control over the main mix before it reaches the sound system.
Routing, Effects, and USB Recording
The console provides 6 AUX sends, 2 FX sends, 4 group buses, a stereo bus, 2 matrix outputs, and a mono output for monitor, zone, and main feed routing. Dual digital effects run at the same time, pairing REV-X with 8 programs and SPX with 16 programs. The built-in USB device recorder can capture WAV or MP3 files and play back MP3, WAV, and AAC audio, making it useful for event capture, playback cues, and reference recordings.
The MGP32XA also uses an internal 100 to 240 V, 50/60 Hz power supply. Its 40.4-inch width gives engineers a large physical control surface with dedicated faders and channel strips, while the 41.9-pound chassis suits front of house, education, house of worship, event production, and installed audio workflows.
General
Mixing Capacity:
| Mixing Channels | 32 line inputs, 24 mono and 4 stereo |
| Mic Inputs | 24 |
| Phantom Power | 48V per channel |
| Line Inputs | 24 mono and 4 stereo |
| Channel Inserts | 24 |
| Stereo Return | 1 stereo |
| Group Buses | 4 group buses plus stereo bus |
| AUX Sends | 6 |
| FX Sends | 2 |
| Matrix Outputs | 2 |
| Mono Output | 1 |
| Digital I/O | USB device |
Signal Processing:
| FX1 | REV-X, 8 programs |
| FX2 | SPX, 16 programs |
| Input Channel Compressor | Channels 9 through 24 |
| High Pass Filter | 100 Hz, 12 dB per octave |
| Mono Channel EQ | X-pressive EQ |
| Stereo Master Processing | Graphic EQ, standard compressor, and multiband compressor |
| Stereo Hybrid Channel Functions | Priority Ducker, Leveler, and Stereo Image |
USB Recording and Playback:
| Recording Formats | WAV and MP3 |
| Playback Formats | WAV, MP3, and AAC |
| Recording Sources | Stereo output or Matrix outputs 1 and 2 |
Audio Performance:
| Total Harmonic Distortion | 0.02 percent, 20 Hz to 20 kHz at plus 14 dBu |
| Frequency Response | plus 0.5 dB, minus 1.0 dB, 20 Hz to 20 kHz |
| Equivalent Input Noise | minus 128 dBu |
| Residual Output Noise | minus 92 dBu |
| Crosstalk | minus 74 dB at 1 kHz |
Analog Inputs:
| Mono Channel Inputs 1 through 24 | XLR and phone jack connections |
| Stereo Channel Inputs 25 through 32 | Phone jack and RCA pin jack connections |
| Talkback Input | XLR connection |
Analog Outputs:
| Stereo Out L and R | XLR and phone jack, plus 4 dBu nominal, plus 24 dBu maximum |
| Mono Out | XLR, plus 4 dBu nominal, plus 24 dBu maximum |
| Group Out 1 through 4 | Phone jack, plus 4 dBu nominal, plus 20 dBu maximum |
| AUX Send 1 through 6 | XLR, plus 4 dBu nominal, plus 24 dBu maximum |
| Matrix Out 1 and 2 | Phone jack, plus 4 dBu nominal, plus 20 dBu maximum |
| Monitor Out L and R | Phone jack, plus 4 dBu nominal, plus 20 dBu maximum |
| Phones Out | Stereo phone jack, 3 mW nominal and 75 mW maximum with 40 ohm phones |
Power and Physical:
| Power Requirements | 100 to 240 V, 50/60 Hz |
| Power Consumption | 86 W maximum |
| Dimensions | 1,027 mm W x 169 mm H x 565 mm D, 40.4 inches W x 6.7 inches H x 22.2 inches D |
| Net Weight | 19 kilograms, 41.9 pounds |
